5000 Series Heavy Duty Sliding Doors
We build very heavy duty sliding aluminium doors here in Sydney, designed and manufactured to your specifications. These doors are very generous in size, making them ideal for larger applications that need bigger doors. And, because they open horizontally across a track, they help to further maximise space. Whether you need new doors for luxury apartments, or another residential or commercial renovation, make them your own with B&W Windows & Doors.
Look through the benefits and standard features for our Commercial Doors. Further options are also available, and your doors will be made-to-measure. All Commercial doors are manufactured to your specifications within our purpose-built aluminium windows and doors factory here in Sydney.
Colour Choices
Aluminium Windows and Doors From B & W Windows ansd Doors comes in many colour choices for your requirement. Below are some of our most popular colours. To check out the full colour range, view the Colour Chart.
Popular Colours
| White Birch | Ultra Silver | Paper Back | Dune |
Popular Colours
| Pearl White | Surf White | White Birch | Ultra Silver |
Get A Custom Quote
Exceptional quality sliding doors made in Sydney
Our sliding doors deliver the highest possible ratings on a sliding door, for exceptional weather protection. They’re also a leading choice in aesthetics. Cavity doors give the impression of disappearing into the walls – for view maximisation and to enable more natural light to flood throughout the home.
Perfect for larger applications, door panel height can reach up to 2700mm, and width to 1500mm, with multiple combinations from 3-6 panels. 2 panel doors include one fixed and one sliding panel, plus fly screen, while 3 panel doors include two fixed and one sliding panel, plus fly screen.
Standard & optional features
The following features come as standard with all heavy duty, commercial grade sliding doors:
- Glass – 6.38 Clear Laminated, A-Grade safety glass
- Locks – Shopfront Mortice Lock
- Frame – 150mm
- Rubber – Black
- Ratings – 450PA Water and 2400PA Wind (with subsill)
- Flat Sill
- Have 3 or more panels in one frame without using an adapter
- Sash – two sashes
B&W Windows & Doors will work with builders and homeowners to modify and add-on to aluminium doors, for a bespoke result.
Choose from single glazed (up to 10.38mm) or double glazed (up to 28mm) glass, in any of the following types:
- Laminated
- Toughened
- Low-e
- Plus, more
Glass colour options include:
- Clear
- Grey (tinted)
- Translucent
- Plus, more
All powder coated colours are either in the Interpon and Dulux range. Keyed locks are available in white, black, and satin chrome.
Place an order or find out more
To place an order for luxury sliding doors in Sydney, contact our team. If you’d like further information about our products, made to measure process, or optional add-ons, give us a call on 61 2 9540 2500 or email info@bwwindows.com.au.
| STANDARD FEATURES | |
| Glass | 6.38mm clear laminated A grade safety glass |
| Frame | 100mm |
| Ratings | 450PA Water and 2400PA Wind (with subsill) |
| Lock | Austral Pearl |
| Width | 101.6mm |
| MAXIMUM SIZING | |
| Height 2100mm / Width 2100mm 2 panel | |
| Height 2100mm / Width 4500mm 3 panel | |
| CONFIGURATION | |
| SF/FS | |
| SFS |
